Laser marking is a very delicate and effective method of creating depth by eroding the surface material and thereby changing its reflectivity. Since the laser is a non-contact marking technique, it has a variety of advantages over conventional marking systems, including improved precision, speed, and consistency marking for both metal and non-metal surfaces. We aspire to bring you the newest technologies in DPM (Direct Part Marking) and metal marking through our continuous R&D and use advanced components to deliver quality at the most affordable prices.
Product Samples
Zero maintenance machine
No ink, No Chemical, No gas require
No Need Skill Operator
Working on Single Phase
Full Machine Power Load <1 KW
24×7 Hours non Stop Working
Easy to Operate Machine
Save Times & Low Labor Work
- Forget inkjet, pad printing, stickers
- Creative design for customers
- Brand logo printing on non metals
- Sharp & fast precise cutting
- Better solution than pad printing, inkjet , sticker & manual hand cutting
| Sr. No. | Description | Details |
|---|---|---|
| 1 | Laser Power | 100watts |
| 2 | Working area | 600*600mm |
| 3 | Laser Wavelength | 10.60μm |
| 4 | Response time | 0.5ms |
| 5 | Frequency of pulse | ≤ 30KHZ |
| 6 | Max marking depth | ≤0.3mm (adjustable according to materials) |
| 7 | Marking speed | 0-7000mm/s |
| 8 | Marking lines | 1-10 lines (in the marking area) |
| 9 | Minimum line width | 0.1mm |
| 10 | Minimum character | 0.4mm |
| 11 | Repeatability accuracy | ±0.01mm |
| 12 | Resolution ratio | 0.1mm |
| 13 | Marking content | Text, pattern, date, bar code, etc. |
| 14 | Graphic format support | bmp, jpg, gif, tga, png,tif,ai,dxf,dst,plt,etc. |
| 15 | Unit power | ≤ 1.2KW |
| 16 | Operation temperature | 5°C-40°C |
| 17 | Relative moisture | ≤ 90%, nofog |
| 18 | Supply Voltage | 220V/50Hz/15A |
| 19 | Cooling method | water cooling CW5000 water chiller |
WHICH MATERIAL YOU CAN MARK, CUT & ENGRAVE!!
- Acrylic
- Plywood
- Mdf
- Leather
- Crystal
- Rubber
- Plastic
- Paper
- Ceramic
- Marble Fabric
- First and last pulse equally usable.
- Marking are permanent with high abrasion resistance.
- High precision, fasten speed, consistent marking quality.
- Exceptional beam quality result into sharp and minuscule marking.
- Greater than 1,00,000 hours maintenance-free operation.
- Real-time visible live pointer for preview your mark.
- User friendly interface, easy operation.
- Acrylic Sheet
- Modeling
- Plastic Industries
- Wood
- Mdf
- Plywood
- Ro Manufacturer
- Membrane Switch
- Fabrics
- Embroudery
